    WT-62-UNL Micro GPS Tracker Module with UART+TTL Output for Vehicle Tracking

    Ask Lasest Price
    Model Number : WT-62-UNL
    Price : CN¥37.81/pieces 1-499 pieces
    • Product Details
    • Company Profile

    WT-62-UNL Micro GPS Tracker Module with UART+TTL Output for Vehicle Tracking

    WT-62-UNL Micro GPS Tracker Module with UART+TTL Output for Vehicle Tracking
    WT-62-UNL Micro GPS Tracker Module with UART+TTL Output for Vehicle Tracking
    WT-62-UNL Micro GPS Tracker Module with UART+TTL Output for Vehicle Tracking
    Module performance
    Model
    WT-62-UNL
    Receiver type
    GPS/QZSS :L1C/A
    Galileo:E1-B/C
    GLONASS:L1OF
    BeiDou:B1|
    Agreement
    NMEA-0183 compliant protocol or custom protocol
    Channel
    72
    Available baud rate
    4800bps~921600bps(default 9600bps)
    Sensitivity
    Tracking: -167dbm Capture: -158dbm Cold start -148dbm
    Cold start
    Average 26 seconds
    Hot start
    Average 1 seconds
    Accuracy
    Horizontal Position : average, SBAS < 2.0m
    Max Height
    18000 m
    Max Speed
    515 m/s
    Max Acceleration
    ≦ 4G
    Regeneration frequency
    1Hz -18 Hz
    Port
    Port
    UART+TTL
    Physical property
    Type
    24 pin stamp holes
    Size
    16.0mm*12.2mm*2.4mm(+/- 0.5mm)
    Power supply
    Voltage
    1.65V~3.6V
    Power Consume
    Operation mode: 21 mA@3.0V, power saving mode: 5.3 mA@3.0V (PSM, 1hz)
    Oerating Environment
    Humidity range
    5% to 95% non-condensing
    Working Temperature
    -40℃ to 85℃
    Storage Temperature
    -40℃ to 85℃
